製品寸法
HEICO-Tec® 組立キット
強度区分 8
強度区分 10
| M | 品番 | 数量ワッシャ ― | プレッシャーボルト 本数 | プレッシャーピン 本数 |
|---|---|---|---|---|
| M20 | HTM-M20/8 | 1 | 7 | 7 |
| M24 | HTM-M24/8 | 1 | 8 | 8 |
| M27 | HTM-M27/8 | 1 | 10 | 10 |
| M30 | HTM-M30/8 | 1 | 9 | 9 |
| M33 | HTM-M33/8 | 1 | 10 | 10 |
| M36 | HTM-M36/8 | 1 | 7 | 7 |
| M39 | HTM-M39/8 | 1 | 8 | 8 |
| M42 | HTM-M42/8 | 1 | 9 | 9 |
| M45 | HTM-M45/8 | 1 | 8 | 8 |
| M48 | HTM-M48/8 | 1 | 9 | 9 |
| M52 | HTM-M52/8 | 1 | 10 | 10 |
| M56 | HTM-M56/8 | 1 | 8 | 8 |
| M60 | HTM-M60/8 | 1 | 9 | 9 |
| M64 | HTM-M64/8 | 1 | 10 | 10 |
| M68 | HTM-M68/8 | 1 | 9 | 9 |
| M72 | HTM-M72/8 | 1 | 10 | 10 |
| M76 | HTM-M76/8 | 1 | 12 | 12 |
| M80 | HTM-M80/8 | 1 | 13 | 13 |
| M85 | HTM-M85/8 | 1 | 15 | 15 |
| M90 | HTM-M90/8 | 1 | 13 | 13 |
| M95 | HTM-M95/8 | 1 | 15 | 15 |
| M100 | HTM-M100/8 | 1 | 16 | 16 |
| M105 | HTM-M105/8 | 1 | 14 | 14 |
| M110 | HTM-M110/8 | 1 | 15 | 15 |
| M115 | HTM-M115/8 | 1 | 17 | 17 |
| M120 | HTM-M120/8 | 1 | 18 | 18 |
| M | 品番 | 数量ワッシャ ― | プレッシャーボルト 本数 | プレッシャーピン 本数 |
|---|---|---|---|---|
| M20 | HTM-M20/10 | 1 | 10 | 10 |
| M24 | HTM-M24/10 | 1 | 12 | 12 |
| M27 | HTM-M27/10 | 1 | 9 | 9 |
| M30 | HTM-M30/10 | 1 | 12 | 12 |
| M33 | HTM-M33/10 | 1 | 8 | 8 |
| M36 | HTM-M36/10 | 1 | 10 | 10 |
| M39 | HTM-M39/10 | 1 | 12 | 12 |
| M42 | HTM-M42/10 | 1 | 10 | 10 |
| M45 | HTM-M45/10 | 1 | 11 | 11 |
| M48 | HTM-M48/10 | 1 | 12 | 12 |
| M52 | HTM-M52/10 | 1 | 11 | 11 |
| M56 | HTM-M56/10 | 1 | 12 | 12 |
| M60 | HTM-M60/10 | 1 | 13 | 13 |
| M64 | HTM-M64/10 | 1 | 12 | 12 |
| M68 | HTM-M68/10 | 1 | 13 | 13 |
| M72 | HTM-M72/10 | 1 | 12 | 12 |
| M76 | HTM-M76/10 | 1 | 13 | 13 |
| M80 | HTM-M80/10 | 1 | 14 | 14 |
| M85 | HTM-M85/10 | 1 | 13 | 13 |
| M90 | HTM-M90/10 | 1 | 14 | 14 |
